Home » Products » Wire to Boards » Pitch 2.0 mm
Pitch: 2.0 mm

Pitch: 2.0mm

No. of Poles: 2 -16 Pins

Current rating: 2.0A AC/DC

Voltage rating: 125 V AC/DC

Contact resistance: 20m ohm.max

Insulation resistance: 1000M ohm.Min

Withstanding voltage: 500V AC for one minute

Operating temperature range: - 40°C to + 85°C

Insulator: High Temp.Plastic (UL94V-0)

Contact: Copper Alloy

Plating: Tin Plated
