ITPPL is your comprehensive source for all types of relay solutions..
As a trusted supplier of YOI relays and a wide variety of electronic components, we offer premium-quality products at competitive prices. Our portfolio includes telecom relays, power relays, automotive relays, high-current relays, sugar cube relays, and more—available in multiple specifications to match your application needs. Choose from a range of voltage levels, current ratings, shapes, and configurations to find the perfect fit for your requirements.
Interested in our products?
We are here to help. Reach out to us anytime at 📞 +91-9810023414 or 📧 sales@itpindia.in. Whether your order is large or small, we will assist you.
Please visit our download page for complete YOI Catalogue.
Outline L*W*H (mm): 20.5x10.0x11.8
Contact Form: 2Z
Max. Operating Current: 2A
Minimum Load: 1mA 5VDC
Max. Operating Voltage: 240VAC/60VDC
Max. Operating Power: 120VA/60W
Rated Voltage: 3-48VDC
Terminal Type: PCB
Outline L*W*H (mm): 15.8x10.8x11.8
Contact Form: 1Z
Max. Operating Current: 5A
Minimum Load: 1mA 5VDC
Max. Operating Voltage: 240VAC/60VDC
Max. Operating Power: 360VA/90W
Rated Voltage: 3-48VDC
Terminal Type: PCB
Outline L*W*H (mm): 15.8x10.8x11.8
Contact Form: 1Z
Max. Operating Current: 5A
Minimum Load: 1mA 5VDC
Max. Operating Voltage: 240VAC/60VDC
Max. Operating Power: 360VA/90W
Rated Voltage: 3-48VDC
Terminal Type: PCB
Outline L*W*H (mm): 12.4x7.4x10.0
Contact Form: 1Z
Max. Operating Current: 2A
Minimum Load: 1mA 5VDC
Max. Operating Voltage: 120VAC/60VDC
Max. Operating Power: 240VA/48W
Rated Voltage: 3-24VDC
Terminal Type: PCB
