Specifications |
 |
|
 |
Flexible Copper Conductors |
Insulation:- PVC Compound with properties as per IS:- 5831 |
Suitable for 70°C, 85°C or 105°C as required |
Colour/Sequence:- Black, Brown, Red, Orange, Yellow,Green, Blue, Violet, Grey & White and Colour Sequence - as per Customer's requirment |
Standard Length:- 300 mtr/ or as per Customer’s Order (100 Mtr -500 Mtr) |
Rated Voltage Up to & Including 1100 Volts |
Flammability: Period of burning of wire after removal of flame – < 60 sec |
Wire available in Size 7/38, 9/38, 11/38, 14/38, 7/36, 9/36, 12/36, 14/36, 7/36 PTT |
Wire available in 2 cores to 10 cores |
|
|
 |
|
|
|
Applications |
|
|
|
Used in Electronics,Lighting, Entertainment, Music, PA Audio Systems, PCB Assemblies with Lithium Batteries, LED Panels etc. |
Low Tension Electric Wire for Automobiles Used in Motor Vehicles for lighting, charging and instrument panel circuits.
|
|
|
|
|
|
